Terex Demag CC2400-1
Login to view detailed pricing and rental terms
Description
Model: CC2400-1 · Capacity: 400 ton · Boom: 84 m · Luffing jib: 60 m · Mast: 30 m · Hook blocks: 2 × 200 t, 160 t, 50 t, 16 t · Counterweight: 200 t, with tray-type Superlift (full Superlift counterweights available). A 400-tonne lattice boom crawler crane with Demag's IC-1 touchscreen control and modular Superlift configurations, built for heavy industrial and energy-sector lifts across the UAE.
Rental Includes:
- • Equipment inspection reports
- • Mob/Demob service
- • 24/7 technical support
- • Comprehensive insurance coverage
- • Certified operator
- 400 tMax capacity @ 6 m
- 5,168 t·mMax load moment
- 126 mMax main boom
- 168 mMax tip height
- 84 + 60 mBoom + luffing jib on our unit
Working ranges
Boom systems & Superlift
Main boom, luffing jib, fixed jib and Superlift configurations from one base crane. Pick a system.
| Main boom | Value | Note |
|---|---|---|
| Main boom length | 24 – 126 m | 79–413 ft; our unit: 84 m |
| Max capacity | 400 t @ 6 m | 2 × 200 t hook blocks |
| Max load moment | 5,168 t·m | |
| Max tip height | 168 m | 551 ft |
| Luffing jib | Value | Note |
|---|---|---|
| Luffing jib length | 18 – 84 m | 59–276 ft |
| On our unit | 84 m boom + 60 m jib | With 30 m mast |
| Fixed jib | Value | Note |
|---|---|---|
| Fixed jib length | 12 – 36 m | 39–118 ft, for extra hook height on the main boom |
| Counterweight & Superlift | Value | Note |
|---|---|---|
| Main counterweight | up to 160 t | |
| Central ballast | 40 t | |
| On our unit | 200 t | 160 t + 40 t central ballast |
| Superlift counterweight | up to 240 t | Tray type, variable; full set available |
| Hook block on our unit | Typical use |
|---|---|
| 2 × 200 t | Paired for max-capacity lifts up to 400 t |
| 160 t | Heavy lifts at mid radius |
| 50 t | Luffing jib and long-reach work |
| 16 t | Single-line, fast hoisting |
Technical data
CC2400-1 specifications
Lifting & reach
- Max lifting capacity400 t @ 6 m
- Max load moment5,168 t·m
- Main boom24 – 126 m
- Luffing jib18 – 84 m
- Fixed jib12 – 36 m
- Max tip height168 m
Weights & ballast
- Main counterweightup to 160 t
- Central ballast40 t
- Superlift counterweightup to 240 t
- Counterweight on our unit200 t + tray Superlift
- Base weightapprox. 233 – 235 t
Base weight with 100 t counterweight, 24 m boom and hook block.
Power & control
- EngineDaimlerChrysler OM 501 LA
- Engine output260 kW (353 hp) @ 2,000 rpm
- Max travel speed2 km/h
- Control systemDemag IC-1 colour touchscreen
- Mast on our unit30 m
About the brand
Who makes the CC2400-1?
The CC2400-1 was built under the Terex Demag name. Demag mobile cranes were owned by Terex Corporation from 2002 to 2019 and are now part of Tadano Ltd.
IC-1 control system
Colour touchscreen showing load, radius and configuration, with intuitive set-up of each boom system
Modular Superlift
Tray-type Superlift with variable ballast up to 240 t for long-reach, heavy-duty lifts
Luffing jib reach
Luffing jib from 18 m to 84 m for lifting over obstructions inside plants and refineries
Full crew support
Certified operator, riggers and lift planning with every hire
