DEMAG AC 120
Description
The Demag AC 120 is a versatile, reliable all-terrain crane that combines strong lifting performance with excellent mobility and precision. It drives efficiently between job sites, making it ideal for construction, industrial, infrastructure and maintenance projects.
Rental Includes:
- • Equipment inspection reports
- • Mob/Demob service
- • 24/7 technical support
- • Comprehensive insurance coverage
- • Certified operator
Key features
- All-terrain mobility for highway and off-road access
- Telescopic main boom for fast setup and flexible operation
- Compact design for confined job sites
- Advanced control systems for precise lifting
- Efficient transport configuration with reduced setup time
The telescopic boom allows rapid deployment and smooth operation. Lifting capacity varies with boom length, working radius, counterweight and outrigger setup. Official load charts are available on request.
- 120 tMax capacity (125 t hook block)
- 60 mTelescopic main boom
- 60 + 17 mBoom + longest extension
- 80 km/hMax road speed
- 5 axles12 t per axle, 60 t on road
Working ranges
Boom, extension & counterweight
Standard duty charts exist for every boom length and counterweight below, on full or reduced outrigger spread.
| Main boom length | Outriggers 7.65 × 7.50 m | Outriggers 7.65 × 5.40 m |
|---|---|---|
| 12.9 / 17.6 / 22.3 m | 5.6, 16.8, 28, 38 t | 16.8, 28, 38 t |
| 27.0 / 31.7 / 36.3 m | 5.6, 16.8, 28, 38 t | 5.6, 16.8, 28, 38 t |
| 41.2 / 45.9 / 50.6 m | 5.6, 16.8, 28, 38 t | 5.6, 16.8, 28, 38 t |
| 55.4 / 57.7 / 60.0 m | 5.6, 16.8, 28, 38 t | 16.8, 28, 38 t |
| Telescoping 10.1 → 60 m | 190 s | |
| Boom elevation −1.5° → +80.5° | 55 s |
| Main boom | Extension (0° / 20° / 40°) | 7.65 × 7.50 m | 7.65 × 5.40 m |
|---|---|---|---|
| 50.6 m | 9.2 m / 17.0 m | 16.8, 28, 38 t | 28, 38 t |
| 55.4 m | 9.2 m / 17.0 m | 16.8, 28, 38 t | 28, 38 t |
| 57.7 m | 9.2 m / 17.0 m | 16.8, 28, 38 t | 28, 38 t |
| 60.0 m | 9.2 m / 17.0 m | 16.8, 28, 38 t | 28, 38 t |
| Setup | Value | Note |
|---|---|---|
| Counterweight stages | 5.6 / 16.8 / 28 / 38 t | 5.6 t can stay on for road travel |
| Full outrigger spread | 7.65 × 7.50 m | All counterweights, all boom lengths |
| Reduced outrigger spread | 7.65 × 5.40 m | For tight sites; see boom tab for limits |
| Hook block | Possible load | Sheaves | Weight | "D" | Max reeving |
|---|---|---|---|---|---|
| 125 | 125.0 t | 9 | 1,300 kg | 2.00 m | 18 (3 add. sheaves) |
| 80 | 79.2 t | 5 | 930 kg | 1.90 m | 11 |
| 63 | 50.0 t | 3 | 700 kg | 1.90 m | 7 |
| 32 | 21.6 t | 1 | 550 kg | 1.80 m | 3 |
| 8 (single line hook) | 7.2 t | — | 250 kg | 1.70 m | 1 |
Technical data
AC 120 specifications
Winches & working speeds (infinitely variable)
- Hoist I, normal / high speed60 / 110 m/min
- Hoist II, normal / high speed60 / 110 m/min
- Max permissible line pull72 kN
- Rope, hoist I and IIØ21 mm × 240 m
- Slewingmax 1.7 rpm
- Telescoping 10.1 – 60 m190 s
- Boom elevation −1.5° – +80.5°55 s
Boom & counterweight
- Main boom12.9 – 60.0 m
- Boom extension9.2 m / 17.0 m
- Extension offset0° / 20° / 40°
- Counterweight5.6 / 16.8 / 28 / 38 t
- Outrigger spread7.65 × 7.50 m / 7.65 × 5.40 m
- Heaviest hook block125 t, 9 sheaves
On the road
- Axles5 × 12,000 kg
- Total travel weight60,000 kg
- Travel speed forward0 – 74 / 80 km/h
- Travel speed reverse0 – 6 km/h
- Gradeability in travel ordermax 60%
- Ground clearance335 / 370 mm
- Tyres14.00 R 25
Axle loads apply to the basic machine with the 9.2 m extension, type 32 hook block and 5.6 t counterweight on board.
Mobilization
Drives to site, sets up fast
No low loader for the crane
The AC 120 drives on public roads at up to 80 km/h with its boom on board
Off-road capable
All-terrain carrier climbs up to 60% grades in travel order, with up to 370 mm ground clearance
Quick rig-up
Telescopic boom extends to 60 m in 190 s; extra counterweight follows on a support truck for heavier duties
Fits tight sites
Reduced 7.65 × 5.40 m outrigger spread with its own duty charts
